| Business Type | Manufacturer, Exporter, Supplier |
| Accuracy | ±0.25% Of SPAN ± 1 Count |
| Resolution | 0.001 To 9999 For Linear Inputs, 1.0 Or 0.1 For Temperature Display |
| Control | 2 Set Of Control Limits, Set-1 Heater Logic & Set-2 Cooler Logic, 5 Amps/220V AC Relay Contact Output, Hysterisis Settable |
| Click to view more | |
Product Details
Calibration
By Software. Ambient By Rear Pot
Configuration Lock
Jumper At Rear
Exciter Voltage
24V @ 30mA For Loop Tx
Rated Power
220V AC ± 15% @ 50/60 Hz
Ambient
0-55˚C
Humidity
Up To 90% (non-condensing)
Power Consumption
10VA
Case
48 X 96 X 180 Mm Plastic ABS
Front Fascia
48 X 96 Mm
Panel Cutout
45 X 92 Mm
Features
- Microprocessor based precision controller
- Linearised for 7 types of common thermocouples & PT100 Temperature sensor with Auto cold junction compensation
- Input for 4-20mA / 0-20mA / 1-5V / 0-5V from Tx for Pressure, Humidity, pH, Temperature etc.
- Display user programmable from 0 to 9999
- 4 Digit 0.56” Bright 7 Segment LEDs
- Decimal user settable
- Separate heater & cooler logic relays
- Hysterisis of relay control settable
- Offset separately programmed from front
- Configuration lockable by rear jumper
- Excitation voltage for loop Tx. Sourced
- Touch type membrane control keys
