| Business Type | Manufacturer, Exporter, Supplier |
| Output | Isolated 4-20mA Re-transmission Output For All Inputs |
| Accuracy | ±0.25% Of SPAN ± 1 Count |
| Resolution | Settable 0.001 To 9999 For Linear Inputs, 1degC For Thermocouples, 0.1degC For PT100 |
| Click to view more | |
Product Details
Control
2 Set Of Control Limits, Set-1 Heater Logic & Set-2 Cooler Logic, 5 Amps/220V AC Relay Output For Set 1, SSR 12V DC Output For Set 2, Hysteresis Settable
Exciter Voltage
24V @ 30mA For Loop Tx
Rated Power
220V AC ± 15% @ 50/60 Hz
Ambient
0-55˚C
Humidity
Up To 90% (non-condensing)
Power Consumption
10VA
Case
48 X 96 X 85 Mm Plastic ABS
Front Fascia
48 X 96 Mm
Panel Cutout
43 X 91 Mm
Features
- Large 4 Digit 0.8” 7 Segment LEDs for Process Value. Separate 0.36” Green Display for Set Value
- PT100 (RTD) sensor & 5 types of common thermocouples with Auto cold junction compensation
- Input for 4-20mA / 0-20mA / 1-5V / 0-5V/ 0-10V from Tx for Pressure, Humidity, pH, Temperature etc.
- Display user programmable from -1999 to 9999
- Decimal user settable
- Heater logic relay and Cooler Logic SSR outputs
- 4-20mA isolated re-transmission output
- Hysterisis for set limits user settable
- Offset separately programmed from front
- Excitation voltage for loop Tx. Sourced
Display
- 4 Digit 0.8” Red 7 Segment LED display for Process Value
- 4 Digit 0.36” Green 7 Segment LED display for Set Value
Inputs
- Linear (Universal from Tx)
- 0-20mA, 4-20mA, 0-5V, 1-5V & 0-10V
- Non-linear (temperature sensors)
- T/C – R,T,J,K,N and 3 Wire PT100
Looking for "Model CT-SV8 Process Controller" ?
