| Business Type | Manufacturer, Exporter, Supplier |
| Resolution | Conductivity: 0.01ms Or 0.01µs, TDS: 1ppm |
| Auto Temp. Comp | 0-100˚C Using PT100 External Sensor |
| Manual Temp. Comp | Settable From 0-100.0˚C |
| Click to view more | |
Product Details
Cond/TDS Calibration
Digital Calibration By Factor Multiplication From 0.75-1.25
Accuracy
0.5% ± 1 Digit
Supply
220V AC ±10% @ 50Hz
Enclosure
Plastic (ABS), Size - 96x96x110mm
Low Voltage
Set At 10.5V Internally, For Testing 12V Battery AH
Weight
900 Grams
Features
- Auto/Manual temperature compensation selectable
- Conductivity and TDS selectable from front panel
- Cell Factor selectable for both 1.0 and 0.1
- 4 Step Range selection 0.1µs to 199.9ms for conductivity
- Digital calibration for Conductivity/TDS
- Auto Temp Compensation using PT100 sensor
- Dual set limit with separate relay outputs
- Settable hysteresis for both set limits
- Bright Red LED display with separate display for set limit-1
- Aesthetically designed front panel with membrane switches and ABS cabinet
Display
- 0.56” Red LED 7 segment Display for Conductivity/TDS
- 0.56” Red LED 7 segment Display for Set-Limit-1
Recorder Output
Isolated 4-20mA => 0-2000 (for whatever unit and resolution selected (Maximum termination 250Ω)
Control Output
- Two set of NO-P-NC, 5 Amps potential free Relay Contacts
- Relay 1 ON, for Cond/TDS < Set Limit1 – Hysterises1, Relay 1 OFF, for Cond/TDS > Set Limit1
- Relay 2 OFF, for Cond/TDS < Set Limit2,Relay 2 ON, for Cond/TDS > Set Limit2 + Hysterises2
