Model 254D Programmable Digital Counter

Link Copied
Business Type Manufacturer, Exporter, Supplier
Range Maximum Count Of 9999
Set Points Single Set Points Programmable From 1-9999
Batch Limit Batch Limit Setting From 0 To 999
Click to view more

Product Details

Operating Modes
A. Auto Mode (Time Settable) B. Manual Mode (Delay Set To Zero)
Input Frequency
0 To 1 KHz
Sensor Supply
10V DC, Short Circuit Protected
Multiplying Factor
Programmable From 1-99
Division Factor
Programmable From 1 To 99
Reset Input
A. Front Panel B. Remote Reset By Rear Terminals
Relay Outputs
NO-Pole-NC Contact Rated At 5Amp @ 230 V AC
Memory Retention
10 Years
Configuration Lock
By Password
Mounting
Panel Mounting
Size
96mm X 96mm. Depth 50mm
Weight
Approx. 375 Gms.
Operating Temp.
0-50˚C
Humidity
95% RH

Features

  • 4 Digit Preset Counter with separate displays for Count and Set Limit
  • Large 0.8” display for count, 0.56”
  • Programmable Multiplying and dividing factor.
  • Pre-settable Batch Counter
  • Up/Down Counting Selectable
  • Normal/Auto-Reset with Time setting
  • Non-Volatile memory to hold settings and counts
  • Password for Program configuration lock
