| Business Type | Manufacturer, Exporter, Supplier |
| Power Source | Electric |
| Application | Indsustrial Usage |
| Feature | Accuracy, Durable, Low Power Comsumption |
| Click to view more | |
Product Details
Availability
800 grams
Display
6 RED 7 Segment LEDs of 0.56” character height.
Current Display
Max 9999 Amps using a shunt of current/75mV. User programmed.
Max shunt
Max value of 9999 Amp corresponding to 75mV
Supply
220V AC +/- 10%
Size
Front Fascia 96mm x 96mm Din Size. Depth 135mm. Cut Out : 91mm x 91mm.
Features
- Current Integrated Display
- 4 DIG AMP-HOUR (Selectable: AH , 0.1 AH, AMin & 0.1 AMin)
- Presetable Limit for Amp-Hour with Relay Out,
- 6 Digit Totalizer AH Stored in EEPROM & Front Resettable
- Displays Current in Amps
- Lockable Scale Factor -CAL- for Various Shunts
- Signal Input in mV from Current Shunt of 75mV/Amp
- Application in Constant Thickness Electroplating which is Proportional to Preset AH Limit, irrespective of Voltage/ Current Variation.
- Simultaneous Input for mV(from Current Shunt) and Battery Voltage, to measure the AH of a chargeable Battery when Voltage falls to Factory-Settable Limit( usually 10.5V for 12V Batt)
Looking for "220V Programmable AMP Hour Meter" ?
